25W horticultural luminaire, low heat design, daisy-chainable on one single power source
NGRO25 is a 25W horticultural LED luminaire rated at 2.4 to 2.7 µmol/J, producing 60 to 67.5 µmol/s of PPF over a 120° beam. Its low heat design allows it to be hung directly over the crop, and units can be daisy chained on one single power source from a 120-277V AC 50/60Hz supply with a power factor above 0.9 and THD below 25. The IP 65 profile measures L1195 x W33 x H32mm and weighs 0.38 kg, with a 50,000h rated life and a maximum ambient temperature of 104 °F / 40 °C.
| Input Voltage | 120-277V AC |
| Frequency | 50/60Hz |
| Power Factor | >0.9 |
| THD | < 25 |
| Connection | Daisy-chainable on one single power source |
| Ingress Protection | IP 65 |
| Max. Ambient Temperature | 104 °F / 40 °C |
| Dimensions | L1195 x W33 x H32mm (L47.04" x W1.30" x H1.26") |
| Net Weight | 0.38 kg / 0.84 lbs |
| Thermal Design | Low heat design, can be hung directly over the crop |
| PPFD Measurement Height | 6" / 152 mm |
| Efficiency | 2.4 - 2.7 µmol/J |
| Light Output PPF | 60 - 67.5 µmol/s |
| Beam Angle | 120° |
| Rated Life | 50,000h |
| Model | Power | Efficiency | Light Output PPF | Beam Angle | Max. Ambient Temperature | Dimensions | Net Weight |
|---|---|---|---|---|---|---|---|
| NLC-NGRO25 | 25W | 2.4 - 2.7µmol/J | 60 - 67.5µmol/s | 120° | 104 °F / 40 °C | L1195 x W33 x H32mm (L47.04" x W1.30" x H1.26") | 0.38kg / 0.84 lbs |
* Values as published in the NLC product catalogue
