Seamless Light. Solid Performance.
MALLIA is a compact outdoor recessed step light with a clean, flush-mounted design. Built with durable die-cast aluminum housing and ultra-white tempered glass, it delivers comfortable, high-quality illumination for facades, pathways, and landscape applications with reliable IP65 protection and IK09 impact resistance.
Available in single-color (1700K–6500K), RGB and RGBW configurations with full DMX/DALI/Triac/PWM dimming support.
| Input Voltage | DC 12V/24V/48V · AC 100–240V · 50/60Hz |
| Power Factor | >0.5 |
| Surge Protection | 1KV (L-N) · 2KV (L/N-PE) |
| Electrical Class | DC: Class III · AC: Class I |
| Dimming | Triac · 1-10V · DALI · PWM |
| Working Temperature | -20°C to +50°C |
| Operating Humidity | 95% RH |
| Ingress Protection | IP65 |
| Impact Resistance | IK09 |
| Dimensions | D80 / D50 × H60 mm / L80 × W80 × H60 mm / D71 × H76 mm |
| Housing | Die-Cast Aluminum |
| Mounting | Recessed Wall Mounted |
| Light Window | Ultra-white Tempered Glass |
| Cable Gland | IP65 Copper Nickel-Coated |
| LED Type | SMD3535 |
| Lifetime | L70B50 > 30,000h |
| Switching Cycles | >15,000 times |
| CRI | Standard >80 · Optional >90 |
| Warranty | 3 Years (extendable to 5) |
| Model | Power | Lumen | Beam Angle | CRI | Notes |
|---|---|---|---|---|---|
| NLC-MLI3W | 1×1–3W | 120 lm | 45° | ≥80 | Single LED · RGB/RGBW |
* Values based on CCT 3000K | ±10% tolerance
