Clean lines. Smooth illumination.
FABRIC is a contemporary wall light with a crisp, geometric form that delivers clean, uniform illumination. Its minimalist design makes it a versatile choice for modern indoor or outdoor settings, from façades to entryways.
Available in 7W (300 lm, single-side) and 14W (2 × 300 lm, dual-side). Features tempered frosted glass for soft, glare-free output and an asymmetric 87° × 60° beam for wide façade coverage.
| Input Voltage | 220–240VAC · 50/60Hz |
| Power Factor | >0.95 |
| THD | <15 |
| Surge Protection | 1KV (L-N) · 2KV (L/N-PE) |
| Electrical Class | Class I |
| Dimming | Optional |
| Switching Cycles | >15,000 times |
| Working Temperature | -20°C to +50°C |
| Operating Humidity | 20–85% RH |
| Ingress Protection | IP65 |
| Impact Resistance | IK03 |
| Housing | Die-Cast Aluminum |
| Mounting | Wall Mounted |
| Optics | Tempered Frosted Glass |
| Body Finish | Powder-Coated |
| Body Colors | Bronze · Black · White · Dark Gray |
| Dimensions | W200 × H45 mm (single side) |
| LED Type | SMD |
| Lifetime | L70B50 > 35,000h |
| CRI | Standard >80 · Optional >90 |
| Switching Cycles | >15,000 |
| Warranty | 5 Years |
| Model | Power | Lumen | Efficiency | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-FB 7W | 7W | 300 lm | 21 lm/W | 87° × 60° | >80 · >90 opt |
| NLC-FB 14W | 14W | 2 × 300 lm | 42 lm/W | 87° × 60° | >80 · >90 opt |
* Values based on CCT 3000K | ±10% tolerance | 14W is dual-side (up + down emission).
