Focused Light. Flexible Design.
TORRIS is a compact track-mounted spotlight delivering directional illumination built for highlighting architectural and retail displays. Its anti-glare reflector optics and smooth 350° rotation / 90° tilt make fine beam aiming effortless.
Available in 23W (2,980 lm, 129 lm/W) and 39W (5,226 lm, 134 lm/W) with multiple beam-angle selections. COB source, CRI >90 (optional >95), and backed by a 5-year warranty.
| Input Voltage | 220–240VAC · 50/60Hz |
| Power Factor | >0.95 |
| THD | <10 |
| Surge Protection | 1KV (L-N) · 2KV (L/N-PE) |
| Electrical Class | Class II |
| Dimming | Optional |
| Flicker-Free | Yes |
| Working Temperature | -20°C to +45°C |
| Operating Humidity | 10–85% RH |
| Ingress Protection | IP20 (Indoor) |
| Switching Cycles | >25,000 |
| Housing | Aluminum |
| Mounting | Track Mounted |
| Optics | Reflector (Anti-Glare) |
| Body Finish | Powder Coating |
| Body Colors | Black · White |
| Rotation | 350° |
| Tilt | 90° |
| Dimensions (23W) | H1 171 · H2 84 × D84 mm |
| Dimensions (39W) | H1 192 · H2 101 × D101 mm |
| LED Type | COB |
| Lifetime | L70B50 > 50,000h · L80B20 > 30,000h |
| CRI | Standard >90 · Optional >95 |
| Switching Cycles | >25,000 |
| Warranty | 5 Years |
| Model | Power | Lumen | Efficiency | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-TR 23W | 23W | 2,980 lm | 129 lm/W | 21° / 40° / 60° | >90 · >95 opt |
| NLC-TR 39W | 39W | 5,226 lm | 134 lm/W | 22° / 33° / 55° / 68° | >90 · >95 opt |
* Values based on CCT 3000K | ±10% tolerance
