Dual-lens round surface-mounted emergency light at 200 lm/W.
The STAID S is a compact round surface-mounted non-maintained emergency light with a high-lumen 3535 LED reaching 200 lm/W. An interchangeable circle or corridor lens tailors the distribution to the space, with over 3 hours of battery backup.
Toolfree push-fit terminals, flame-retardant polycarbonate body, white / black / grey finish. CE verified.
| Source | LED |
| LED Source | High-lumen 3535 · 1×6W · 200 lm/W |
| Power / Lumens | 2.7–3.3W · 300–360 lm |
| Input Voltage | 200–240V · 50/60Hz |
| Emergency Backup | >3 Hours |
| Operating Mode | Non-Maintained |
| Test Mode | Dual-mode: Manual + Self-test |
| Mounting | Surface – ceiling |
| Housing | 850°C flame-retardant polycarbonate |
| Ingress Protection | IP20 |
| Weight | 245 g |
| Dimensions | Ø150 mm × H44 mm |
| Body Colour | White / Black / Grey |
| Working Temperature | 0–50°C |
| Warranty | 5 yr product · 4 yr battery |
| Standards | CE · IEC 60598 |
| Battery | NTC LiFePO4 3400/4000mAh |
| Housing | 850°C flame-retardant polycarbonate |
| Mounting | Surface – ceiling |
| Body Colour | White / Black / Grey |
| Operating Mode | Non-Maintained |
| X4D33 | 300 lm · 3.0W |
| X4D43 | 360 lm · 4.0W |
| Lens | Circle / Corridor interchangeable |
Contact our engineering team for detailed photometric data, custom configurations, and ordering codes.
