Linear Light
TRIO L
Tri-proof linear light in 1200mm and 1500mm
IP65
IK08
Up to 160 lm/W
23-60W
Power
3,680-9,600 lm
Lumens
160 lm/W
Efficiency
120°
Beam Angle
>80 / >90 opt
CRI
100,000h
Lifetime
Tri-proof linear light in 1200mm and 1500mm
TRIO L is a tri-proof linear luminaire in two lengths: 1200mm (23W to 40W) and 1500mm (35W to 60W). It has a grey RAL 7035 body, an IK08 impact rating and Class I earthing.
Microwave and PIR sensor options are available. Colour temperatures: 3000K, 4000K, 5000K and 6500K.
| Input Voltage | 220-240VAC · 50/60Hz |
| Power Factor | >0.9 |
| THD | <20 |
| Electrical Class | Class I |
| Ingress Protection | IP65 |
| Impact Rating | IK08 |
| Body Colour | Grey (RAL 7035) |
| Lifetime | 100,000h |
| Lengths | 1200 mm · 1500 mm |
| Body Colour | Grey (RAL 7035) |
| Sensor Options | Microwave sensor · PIR sensor |
| Beam Angle | 120° |
| CRI | Standard >80 · Optional >90 |
| CCT | 3000K · 4000K · 5000K · 6500K |
| Model | Power | Efficiency | Lumen | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-TOL 1200 mm | 23W / 28W / 34W / 40W | 160 lm/W | 3,680 / 4,480 / 5,440 / 6,400 lm | 120° | >80 std, >90 opt |
| NLC-TOL 1500 mm | 35W / 43W / 51W / 60W | 160 lm/W | 5,600 / 6,880 / 8,160 / 9,600 lm | 120° | >80 std, >90 opt |
* Values from the NLC catalog (Commercial Lights), page 51
