All-in-two solar street luminaire for roads, parking and infrastructure lighting.
The S501 is a post-top solar street luminaire from NLC's ST Series, built for outdoor roadway and area lighting in the Kingdom's climate. Available in 40W, 70W, 90W, 120W and 140W with an efficacy of 130 lm/W, delivering up to 18,200 lumens.
Built with a die-cast aluminum housing and tempered-glass diffuser, rated IP66 / IK08 and backed by a 5-year warranty. Charging time is 6–8 hours via an 18V solar panel, with optional dimming, photocell, timing, intelligent power saving and microwave/PIR sensor control.
| Power | 40W / 70W / 90W / 120W / 140W |
| Lumen Output | 5,200 – 18,200 LM |
| Efficacy | 130 Lumens / Watt |
| Power Factor | 0.98 |
| THD | < 10 |
| Solar Panel Voltage | 18V |
| Charging Time | 6 – 8 Hours |
| CRI | > 80 |
| Life Time | 72,000 Hours |
| Housing | Die cast aluminum |
| Diffuser | Tempered glass |
| Mounting | Post top |
| Dimensions (D × H × W) | 541 × 258 × 92 mm |
| Weight (Fixture) | 4.4 – 6.8 Kg |
| Internal Protection | IP 66 |
| Impact Strength | IK 08 |
| Working Temperature | 60°C |
| Warranty | 5 Years |
| Dimming | Available |
| Photocell Sensor | Available |
| Timing | Available |
| Intelligent Power Saving | Available |
| Motion Sensor | Microwave or PIR |
| Battery · Underground | Option |
| Battery · Pole mounted | Option |
| Solar Panel Voltage | 18V |
| Charging Time | 6 – 8 Hours |
| Environmental Note | Free of any hazardous materials |
Contact our engineering team for detailed photometric data, custom configurations, and ordering codes.
