Landscape luminaire, 7W and 603LM in a 39° beam (NLC-ESAR).
Escala is a Class I landscape luminaire for 100-240VAC 50/60Hz supplies, listed in two models, NLC-ESAR and NLC-ESAS. NLC-ESAR draws 7W and delivers 603LM in a 39 degree beam, with colour consistency within 5 SDCM and CRI above 80. The spread carries no performance values for NLC-ESAS. The product is rated IP 54 with a 50,000 hour rated life, and is available in 3000K, 4000K and 5000K with black, dark gray, silver, white and rust finishes.
| Input Voltage | 100-240VAC |
| Frequency | 50/60Hz |
| Protection Class | Class I |
| Ingress Protection | IP 54 |
| Finishes | Black, Dark Gray, Silver, White, Rust |
| Rated Life | 50,000h |
| CRI | Standard: >80 |
| SDCM | <5 |
| CCT Options | 3000K Warm, 4000K Cool, 5000K Daylight |
| Model | Power | System Lumen | SDCM | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-ESAR | 7W | 603LM | <5 | 39° | Standard: >80 |
| NLC-ESAS |
* Values as published in the NLC product catalogue
