Crisp, Clear Light for Every Corner
The PROJECTO flood light delivers up to 160 lm/W in a linear, multi-installation design. Ring mount, pole mount, and long-arm mount options give maximum flexibility for tunnels, stadiums, loading bays, and large outdoor areas.
| Input Voltage | 100–277VAC | 50/60Hz |
| Power Factor | >0.95 @ 220V / >0.90 @ 100–277V |
| THD | <10 @ 220V / <20 @ 100–277V |
| Surge Protection | Internal: DM 6KV/CM 10KV, External: 10KV/20KV |
| Electrical Class | Class I |
| Working Temperature | -30°C to +55°C |
| Operating Humidity | 20–70% RH |
| Dimensions | 50W: H280×L200×W56 mm · 100W: H343×L290×W58 mm · 150W/200W: H390×L341×W64 mm · 300W: H474×L390×W78 mm |
| Housing | Die-cast Aluminum |
| Mounting | Bracket / Pole Mounted |
| Optics | Polycarbonate |
| Body Finish | Electrostatic Polyester Powder-Coated |
| LED Type | SMD2835 |
| Lifetime | L70B50 >50,000h | L80B20 >30,000h |
| Dimming | 0-10V / PWM / Resistor |
| Switching Cycles | >25,000 |
| Emergency Backup | Optional |
| Flicker-Free | نعم |
| Model | Power | Efficiency | System Lumen | Beam Angle | CRI |
|---|---|---|---|---|---|
| NLC-PR | 50W | 160 lm/W | 8,000 lm | 30° / 60° / 90° / 120° / 50°×100° | >70 std · >80 opt |
| NLC-PR | 100W | 160 lm/W | 16,000 lm | 30° / 60° / 90° / 120° / 50°×100° | >70 std · >80 opt |
| NLC-PR | 150W | 160 lm/W | 24,000 lm | 30° / 60° / 90° / 120° / 50°×100° | >70 std · >80 opt |
| NLC-PR | 200W | 160 lm/W | 32,000 lm | 30° / 60° / 90° / 120° / 50°×100° | >70 std · >80 opt |
| NLC-PR | 300W | 160 lm/W | 48,000 lm | 30° / 60° / 90° / 120° / 50°×100° | >70 std · >80 opt |
* Values based on CCT 4000K | ±10% tolerance
* Mounting options: Ring mount · Pole mount · Long-arm mount
