Input Voltage: 220–240VAC | 50/60Hz
Power Factor: >0.95
THD: <15
Surge Protection: 1kV (L-N), 2kV (L/N-PE)
Working Temperature: 45°C
Housing: Aluminum | PC
Mounting: Recessed Mounted
Optics: PMMA / PC
Body Finish: Special Paint
Body Color: Silver
Lifetime: L70B50 > 100,000h | L80B20 > 50,000h
LED Type: COB / SMD (for 40W model)
Emergency Backup: Optional
Dimming: Optional
Flicker Free: Yes
Switching Cycles: >50,000 times
Color Temperatures: 2700K / 3000K / 4000K / 5000K
Model Power Efficiency Lumen Beam Angles CRI
| NLC-LX | 12W | 123 lm/W | 1,476 lm | 15°, 24°, 36°, 60°, 80° | Standard >90 / Optional >95
| NLC-LX | 20W | 123 lm/W | 2,460 lm | 15°, 24°, 36°, 60°, 80° | Standard >90 / Optional >95
| NLC-LX | 30W | 123 lm/W | 4,020 lm | 15°, 24°, 36°, 60°, 80° | Standard >90 / Optional >95
| NLC-LX | 40W | 134 lm/W | 4,920 lm | 15°, 24°, 36°, 60°, 80° | Standard >90 / Optional >95
