Contemporary Light With a Natural Soul
Crafted from durable aluminum with a refined powder-coated frame, OMEGA offers exceptional resistance to weather and corrosion while maintaining a premium aesthetic. The wood-textured panel adds a natural character that softens the rigidity of modern structures, creating harmony between light, form, and material.
🌳 Wood-Textured Panel
Natural wood finish panel with dual lighting modes, Cover Closed (68.5 lm/W) and Cover Open (79.6 lm/W) for flexible ambiance control.
| جهد الدخول | 100–240VAC | 50/60Hz |
| معامل الطاقة | >0.7 |
| تشويه التوافقيات | <15% |
| حماية من الطفرات | 1KV (L-N), 2KV (L/N-PE) |
| Protection Class | Class I |
| درجة حرارة التشغيل | -20°C ~ +55°C |
| رطوبة التشغيل | 10–85% RH |
| IP Rating | IP65 |
| IK Rating | IK05 |
| الأبعاد | L140 × W94 × H140 mm |
| الهيكل الخارجي | Die-Cast Aluminum |
| التثبيت | Wall Mounted |
| البصريات | PC |
| انتهاء الجسم | Electrostatic Polyester Powder-Coated |
| نوع المصباح | SMD2835 |
| Lifetime | L70B50 > 30,000h |
| التعتيم | Optional |
| دورات التبديل | >15,000 |
| الموديل | القدرة | الكفاءة | لومن النظام | زاوية الإنارة | CRI |
|---|---|---|---|---|---|
| NLC-OM | 10.5W | 68.5–79.6LM/W | 719–836LM | 82° / 90° | Standard: >80 · Optional: >90 |
* القيم محسوبة عند CCT 3000K | بهامش ±10%
* Cover Closed: 68.5 lm/W · 719lm · 82° | Cover Open: 79.6 lm/W · 836lm · 90°
